VDHV-L-FB/FM Double Lock Balance Jaw Hydraulic Vise

VDHV-160V/200V-BL/L/XL-FB / FM

Catalogue

Super-Low designed jaw. Best choice for any components!!!
Balance Design!!! Excellent performance with gripper jaw, Flexible for any component.
Clamping system: mechanical / hydraulic type
High Rigidity Material: Ductile Iron FCD 600 JIS (= GGG-60)(60kg/mm2, 80,000 psi ).
Max. opening capacity and compact total length of vise body

Model	VDHV-160V-L-FB	VDHV-160V-XL-FB	VDHV-200V-BL-FB	VDHV-200V-L-FB	VDHV-200V-XL-FB
No	11430160	11432160	11440200	11442200	11444200
A	771	871	845	1025	1170
B	590	690	655	835	980
C	150	150	150	150	150
D	161	161	201	201	201
E	220	220	260	260	260
J	125	175	130	220	295
J1	265	315	305	395	470
K	22	22	22	22	28
N	18	18	18	18	22
X	44	44	51	51	51
Y	105	105	110	110	110
G.W.(KG)	77	83	116	143	159
Shipment size(mm)	660x240x200	760x280x205	840x325x230	1045x410x330	660x240x200
Limit.Pressure	45KN	45KN	50KN	50KN	50KN

Model	VDHV-160V-L-FB	VDHV-160V-XL-FB	VDHV-200V-BL-FB	VDHV-200V-L-FB	VDHV-200V-XL-FB
No	11430160	11432160	11440200	11442200	11444200
A	771	871	845	1025	1170
B	590	690	655	835	980
C	150	150	150	150	150
D	161	161	201	201	201
E	220	220	260	260	260
J	125	175	130	220	295
J1	265	315	305	395	470
K	22	22	22	22	28
N	18	18	18	18	22
X	44	44	51	51	51
Y	105	105	110	110	110
G.W.(KG)	77	83	116	143	159
Shipment size(mm)	660x240x200	760x280x205	840x325x230	1045x410x330	660x240x200
Limit.Pressure	45KN	45KN	50KN	50KN	50KN
