- Ultra-low profile jaw design, perfectly suited for handling thin workpieces.
- Dynamic balance jaw design compatible with grippers to handle various workpiece geometries and complex clamping tasks.
- Clamping System: Power Mechanical
- Robust Material: The vise body is made of high-tensile ductile iron (FCD 600) (60 kg/mm², 80,000 psi), offering high tensile strength and excellent resistance to deformation.
- Specifications Dimensions:
| Model | VQV-100V-FB | VQV-130V-FB | VQV-160V-FB | VQV-200V-FB | VQV-250V-FB |
|---|---|---|---|---|---|
| No | 10220100 | 10220130 | 10220160 | 10220200 | 10220250 |
| A | 406 | 516 | 581 | 661 | 903 |
| B | 300 | 410 | 475 | 555 | 805 |
| C | 106 | 106 | 106 | 106 | 106 |
| D | 101 | 131 | 161 | 201 | 251 |
| E | 160 | 190 | 220 | 260 | 310 |
| J | 100 | 180 | 220 | 250 | 450 |
| J1 | 220 | 320 | 380 | 460 | 700 |
| K | 22 | 22 | 22 | 22 | 22 |
| N | 18 | 18 | 18 | 18 | 22 |
| X | 51 | 60 | 64 | 90 | 276.5 |
| Y | 85 | 95 | 105 | 110 | 115 |
| G.W.(KG) | 20.5 | 35.5 | 54.5 | 93.0 | 159.0 |
| Shipment size(mm) | 590x175x185 | 665x190x225 | 760x190x215 | 820x230x220 | 1045x410x330 |
| Limit.Pressure | 41KN | 45KN | 54KN | 66KN | 70KN |
