- Suitable for precision machining on FMS systems with vertical and horizontal machining centers.
- Adjustable clamping force with clear force indicator; maintains consistent force and precision through repetitive cycles; equipped with overload protection.
- Robust Material: The vise body is made of high-tensile ductile iron (FCD 600) (60 kg/mm², 80,000 psi), offering high tensile strength and excellent resistance to deformation.
- Sliding surfaces hardened to HRC 45°+ for long-term wear resistance and precision retention.
- Fixed and movable steel jaws, heat-treated to HRC 55° and precision ground (easy to assemble/disassemble).
- The chip-cover design prevents machining chips from penetrating the leadscrew and internal areas, avoiding hard-to-clean build-ups.
- Clamping System: Driven by power mechanical
- Large opening is most suitable for large workpiece machining.
- Specifications:
| Model | VQV-160V-L | VQV-160V-XL | VQV-200V-BL | VQV-200V-L | VQV-200V-XL |
|---|---|---|---|---|---|
| No | 10140160 | 10142160 | 10142200 | 10144200 | 10146200 |
| A | 696 | 796 | 761 | 941 | 1086 |
| B | 590 | 690 | 655 | 835 | 980 |
| C | 106 | 106 | 106 | 106 | 106 |
| D | 161 | 161 | 201 | 201 | 201 |
| G | 86 | 86 | 100 | 100 | 100 |
| I | 86 | 86 | 97 | 97 | 97 |
| J/J1 | 400/470 | 500/570 | 450/526 | 630/706 | 780/856 |
| K | 55 | 55 | 60 | 60 | 60 |
| M | 30 | 30 | 30 | 30 | 30 |
| N | 18 | 18 | 18 | 18 | 18 |
| X | 208 | 258 | 227 | 316 | 388 |
| Y | 105 | 105 | 110 | 110 | 110 |
| G.W.(KG) | 72 | 78 | 111 | 138 | 153 |
| Shipment size(mm) | 940x280x220 | 940x280x220 | 809x370x290 | 1205x410x280 | 1300x410x280 |
| Limit.Pressure | 54KN | 54KN | 66KN | 66KN | 66KN |
