Multiple Clamping Vise-MTL-T
Multiple Clamping Vise-MTL-D (Twin-Direction 3-Piece)
Adjustable jaw opening for heavy-duty machining, suitable for both thick and thin workpieces! Clamps two workpieces at once — suitable for both thick and thin parts!
MTL-TMultiple Clamping Vise-MTL allows for adjustable jaw opening, providing more flexible clamping options!
- Flexible opening capacity for optimized application of different workpiece.
- Most suitable for thick workpiece, special design for increasing stability of clamping capacity.
- High clamping forces, suitable for heavy duty working
- All sliding surfaces of the vise base are hardened to maintain long-lasting wear resistance and precision.
- Easy for add-on components for increasing working efficiency
- Model: MTL-A (Single-2 piece) / MTL-D (Single-3 piece) / MTL-T (Twin-3 piece)
- Full ranges from jaw width (50 / 72 / 100) x length (300 / 400 / 500 / 600 / 700)
- Specifications:
| No. | Model | A | B | E | F | H | J | K | L | M | N | P | R | S | W | N.W. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 48207240 | MTL-72-400-T | 400 | 72 | 70 | 40 | 110 | 58 | 42 | 14 | 16 | 18 | 200 | 18 | M16x50Lx4 | 19.3 | |
| 48207250 | MTL-72-500-T | 500 | 72 | 70 | 40 | 110 | 58 | 42 | 14 | 16 | 18 | 300 | 18 | M16x50Lx5 | 22.0 | |
| 48207240 | MTL-72-400-T | 400 | 72 | 70 | 40 | 110 | 58 | 42 | 14 | 16 | 18 | 400 | 18 | M16x50Lx6 | 25.0 | |
| 48207270 | MTL-72-700-T | 700 | 72 | 70 | 40 | 110 | 58 | 42 | 14 | 16 | 18 | 500 | 18 | M16x50Lx7 | 28.5 |
